UPVC flap swing check valve White

Short Description:

upvc plastic swing check valves non return valves have 9 sizes, there are: 3/4″, 1″, 1.2″, 1.5″, 2″, 2.5″, 3″, 4″, 6″.  The smallest size is 3/4″ DN20  25mm;  biggest size is 6″ DN150  160mm. The color of body can be White or Gray, Socket or Female Thread ends with pipes. All standards are available, we can produce it according to client’s standards and body color. UPVC Swing Check Valve Material PVC/UPVC Size 3/4...


  • Port: TianJing
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Video

    Product Tags

    upvc plastic swing check valves non return valves have 9 sizes, there are: 3/4″, 1″, 1.2″, 1.5″, 2″, 2.5″, 3″, 4″, 6″.  The smallest size is 3/4″ DN20  25mm;  biggest size is 6″ DN150  160mm. The color of body can be White or Gray, Socket or Female Thread ends with pipes. All standards are available, we can produce it according to client’s standards and body color.

    UPVC Swing Check Valve

    Material PVC/UPVC
    Size 3/4″–6″  DN20–DN150
    Color Gray; Grey; White
    Connection Socket or Female Threaded
    Installation Vertical or Horizontal installation with pipes
    Logo ATA, or Client’s Logo
    Certificate ISO, Test Report, CO..
    Production capacity 100000/month
    Payment Term TT / LC
    Standards DIN  ANSI  BS JIS CNS TAIWANG
    Quality Guarantee 24 months
    Application • Water & Waste water Treatment
    • Chemical Processing
    • Food & Beverage
    • Swimming Pools & Water Parks
    • Agriculture irrigation system
    • Aquarium & Zoo Service
    • Pharmaceutical
    • Pulp & Paper
    • Landfill Service
    • Marine & Corrosive Environments• All water-related projects & engineering

    Packing & Delivery

    Packing Details
    1. Inner packing small box
      2. Outer packing big export cartons,
      3. Then pallets with wrap film.
      4. Your Logo will be stick on the body of swing check valve
    Delivery Date Swing check valve price will be shipped in 5-30 days.
    Loading port Tianjin port; Shanghai port; Ningbo port; China port.

     1 4

    3 5

    pvc swing check valve




  • Previous:
  • Next:

  • Characteristics:
    Easy connection with Socket or Threaded ending;
    Prevent the back-flow medium;
    Apply to clean medium, not be used in large medium containing solid particles and viscosity;
    Disc closing fast, small water hammer pressure;
    All can horizontal or vertical installation with pipes;
    Flow path unobstructed, small fluid resistant;
    EPDM seal good performance;
    Overall, simple and compact structure, beautiful appearance;
    Long service life, high reliability
